WPJ (W TO B) - Connectors / Wire to Board / Waterproof

Product profile

Application	Connectors
Connector	Wire to Board
Familytype	Waterproof
Technology	Sealed
Pitch	5.0 mm
Smt	no

Spécifications

Current rating	7A AC, DC
Insulation resistance	1000 MOhms min.
Temperature range	-25 to + 85 Celsius degrees
Voltage rating	300V AC, DC
Waterproof grade	IPX7
Compliant with rohs

Download specifications

Compact, Water Resist anCompact, Water Resist and Durable. This connector for electrical connection can be used on both waterproof and non-waterproof conditions, depending on usage. Just by placing a rubber part will change it into a water resistant

Description filter

11 références

To order sample, you must LOG IN

More information use contact form
